Orbea Rise M20 Specs and reviews
Orbea Rise M20 specs
| General Information | |
|---|---|
| Model Name | Orbea Rise M20 |
| Brand/Manufacturer | Orbea |
| Year of Release | 2021 |
| Country of Origin | Spain |
| Electric Bike Type | mountain |
| Intended Use | off-road |
| Frame & Geometry | |
| Frame Material | carbon |
| Frame Size Options | S, M, L, XL |
| Geometry Measurements | reach: 410mm / stack: 620mm / head tube angle: 66.5 degrees / seat tube angle: 76 degrees / wheelbase: 1205mm |
| Axle Type and Standard | Boost 148mm |
| Bottom Bracket Type | standard |
| Headset Type | integrated |
| Internal Cable Routing | yes |
| Motor & Electrical System | |
| Motor Brand and Model | Shimano EP8 |
| Motor Type | mid-drive |
| Motor Power | 250 watts |
| Torque | 85 Nm |
| Pedal Assist Levels | 4 |
| Battery Capacity | 504 Wh |
| Battery Brand and Position | integrated |
| Estimated Range | Up to 100 km |
| Charging Time | Approx. 4-5 hours |
| Charger Specs | Standard charger, 2A |
| Display Type and Features | LCD display |
| App Connectivity or Integration | Shimano E-Tube Project |
| Smart Features | Diagnostics |
| Drivetrain | |
| Drivetrain Type | 1x |
| Number of Speeds | 12 |
| Derailleur Model | Shimano Deore XT |
| Shifter Brand and Model | Shimano Deore XT |
| Crankset Details | length: 170mm / chainring size: 32T |
| Cassette Range | 10-51T |
| Chain or Belt Drive System | chain |
| Braking System | |
| Brake Type | hydraulic disc |
| Brake Brand and Model | Shimano Deore XT |
| Rotor Size | front: 203mm / rear: 203mm |
| Brake Mount Standard | Post mount |
| Wheels & Tires | |
| Wheel Size | 29" |
| Rim Type and Width | Alloy, 30mm |
| Hub Type | thru-axle |
| Tire Brand, Model, Width | Maxxis Minion, 2.6" |
| Tire Type | tubeless-ready |
| Max Tire Pressure | 35 psi |
| Cockpit & Contact Points | |
| Handlebar Type and Width | Riser, 780mm |
| Handlebar Material | Aluminum |
| Stem Length and Angle | 50mm, 7 degrees |
| Grips Type | Lock-on |
| Saddle Brand and Model | Selle Royal 2077 DRN |
| Seatpost Type | rigid |
| Pedals Included | No |
| Accessories & Features | |
| Lights | Front and rear integrated |
| Fenders and Racks | Not included |
| GPS or Anti-Theft Features | Not available |
| Safety & Compliance | |
| Certifications | EN 15194 |
| Water/Dust Resistance | IP54 |
| Performance & Ride Quality | |
| Claimed Weight | Approx. 17 kg |
| Max Assisted Speed | 25 km/h |
| Ride Quality Highlights | Comfort, Stability |
| Packaging & Delivery | |
| Assembly Required | Partial assembly required |
| Box Dimensions | Not specified |
| Shipping Weight | Approx. 25 kg |
| Price & Availability | |
| MSRP | Approx. $6,000 |
| Market Availability | Europe, North America |
| Warranty | frame: 5 years / battery: 2 years / motor: 2 years / electronics: 2 years |
| Color Options | Black, Green |
Pros and Cons of Orbea Rise M20
| Pros | Cons |
|---|---|
| Lightweight carbon frame | High price point |
| Powerful Shimano EP8 motor | Limited range compared to some competitors |
| Smooth and efficient on climbs | May not be suitable for extremely technical trails |
| Modern geometry for agility | Some users may find the saddle uncomfortable |
Common Issues and Problems with Orbea Rise M20
| Common Problems with Orbea Rise M20 Bike |
| 1. Battery range may be limited, especially on highest assistance levels. |
| 2. Motor may produce excessive noise during operation. |
| 3. Display screen issues such as flickering or unresponsiveness. |
| 4. Brake squeaking or rubbing, requiring adjustment or maintenance. |
| 5. Chain slipping or skipping under heavy load. |
| 6. Suspension settings may need fine-tuning for optimal performance. |
| 7. Loose bolts or components that may need periodic tightening. |
User Reviews of Orbea Rise M20
| Review | Name |
| Absolutely love my Orbea Rise M20! The electric assist is a game-changer for long rides. | Sarah |
| The Orbea Rise M20 is a well-designed e-bike with great handling and a smooth ride. | Michael |
| Super impressed with the battery life on the Orbea Rise M20. It lasts much longer than I expected. | Emily |
| As a beginner rider, I found the Orbea Rise M20 easy to use and perfect for exploring new trails. | Jack |
Common Questions About Orbea Rise M20
-
Can I customize the color of the Orbea Rise M20?
No, the Orbea Rise M20 is available in Black and Green color options only.
-
What is the weight of the Orbea Rise M20?
The claimed weight of the Orbea Rise M20 is approximately 17 kg.
-
Does the Orbea Rise M20 come with lights?
Yes, the Orbea Rise M20 comes with front and rear integrated lights.
-
What is the water and dust resistance rating of the Orbea Rise M20?
The Orbea Rise M20 has an IP54 water and dust resistance rating.
-
Is the Orbea Rise M20 pedal-assist only, or can it be ridden without assistance?
The Orbea Rise M20 is a pedal-assist electric bike, meaning it requires pedaling for the motor to engage.
-
Are the fenders and racks included with the Orbea Rise M20?
No, fenders and racks are not included accessories with the Orbea Rise M20.
-
What is the estimated range of the Orbea Rise M20 on a full charge?
The Orbea Rise M20 has an estimated range of up to 100 km on a full charge.
-
Does the Orbea Rise M20 support tubeless tires?
Yes, the Orbea Rise M20 is tubeless-ready, allowing you to set it up with tubeless tires for improved performance.
-
Can I adjust the seat height on the Orbea Rise M20?
Yes, the Orbea Rise M20 comes with a rigid seatpost that allows you to adjust the seat height to your preference.
-
What is the warranty coverage for the electronic components of the Orbea Rise M20?
The electronic components of the Orbea Rise M20, including the motor and battery, are covered under a 2-year warranty.
