KHS XCT 536 Specs and reviews
KHS XCT 536 specs
KHS XCT 536 Accessories
KHS XCT 536 Spare parts
| General Information | |
|---|---|
| Model Name | XCT 536 |
| Brand/Manufacturer | KHS |
| Year of Release | 2022 |
| Country of Origin | Taiwan |
| Mountain Bike Type | cross-country |
| Intended Use | recreational |
| Frame & Geometry | |
| Frame Material | aluminum |
| Frame Size Options | S, M, L, XL |
| Frame Geometry | Reach: 425mm / Stack: 620mm / Head Tube Angle: 68 degrees / Seat Tube Angle: 74 degrees / Chainstay Length: 440mm / Wheelbase: 1140mm |
| Axle Standard | Boost 148mm |
| Bottom Bracket Type | BSA |
| Headset Type | IS42/IS52 |
| Internal Cable Routing | true |
| Frame Storage | downtube storage |
| Protection Features | chainstay protector |
| Suspension System | |
| Suspension Type | full suspension |
| Front Suspension Brand and Model | RockShox Recon Silver |
| Front Suspension Travel | 120mm |
| Rear Suspension Brand and Model | RockShox Deluxe Select |
| Rear Suspension Travel | 110mm |
| Suspension Adjustments | compression, rebound |
| Suspension Design/Kinematics | four-bar |
| Drivetrain | |
| Drivetrain Type | 1x |
| Number of Speeds | 12-speed |
| Rear Derailleur Model | Shimano Deore XT |
| Shifter Brand and Model | Shimano Deore |
| Crankset Details | Length: 175mm / Chainring Size: 32T |
| Bottom Bracket Spec | BSA |
| Cassette Range | 10-51T |
| Chain Type and Brand | Shimano |
| Q-Factor | standard |
| Braking System | |
| Brake Type | hydraulic disc |
| Brake Brand and Model | Shimano Deore |
| Rotor Size | Front: 180mm / Rear: 160mm |
| Brake Mount Standard | post mount |
| Brake Pads | organic |
| Wheels & Tires | |
| Wheel Size | 29" |
| Rim Material and Width | aluminum, 30mm internal |
| Hub Type and Engagement | rapid engagement |
| Tubeless Ready | true |
| Tire Brand, Model, and Width | Maxxis Minion DHF, 2.3" |
| Tire Compound and Sidewall Casing | dual compound, EXO protection |
| Tire Tread Pattern and Intended Terrain | aggressive, all-mountain |
| Max Tire Pressure | 35psi |
| Cockpit & Contact Points | |
| Handlebar Type | riser |
| Handlebar Material | aluminum |
| Stem Length and Angle | 80mm, 6 degrees |
| Grips Type | lock-on |
| Saddle Brand and Model | WTB Volt |
| Seatpost Type | dropper |
| Dropper Post Travel | 150mm |
| Seatpost Diameter | 31.6mm |
| Pedals Included | false |
| Headset Brand and Bearing Type | FSA, sealed |
| Geometry & Fit | |
| Available Frame Sizes | S, M, L, XL |
| Standover Height | S: 745mm / M: 780mm / L: 815mm / XL: 850mm |
| Rider Height Range | 5'5" - 6'3" |
| Stack and Reach | S: Stack 610mm, Reach 420mm / M: Stack 625mm, Reach 440mm / L: Stack 640mm, Reach 460mm / XL: Stack 655mm, Reach 480mm |
| Effective Top Tube Length | 615mm |
| Chainstay Length | 440mm |
| Bottom Bracket Drop and Height | 30mm drop, 335mm height |
| Head Tube and Seat Tube Lengths | S: Head Tube 100mm, Seat Tube 420mm / M: Head Tube 110mm, Seat Tube 450mm / L: Head Tube 120mm, Seat Tube 480mm / XL: Head Tube 130mm, Seat Tube 510mm |
| Price & Availability | |
| MSRP | $2,499 |
| Market Availability | North America, Europe |
| Color Options | Black, Red |
| Warranty Coverage | Frame: 5 years, Components: 1 year |
Pros and Cons of KHS XCT 536
| Pros | Cons |
|---|---|
| Lightweight aluminum frame | May not be as durable as steel frames |
| Smooth suspension for off-road riding | May require frequent maintenance |
| Reliable Shimano drivetrain components | Higher price point compared to some competitors |
| Responsive hydraulic disc brakes | Limited color options |
Common Issues and Problems with KHS XCT 536
KHS XCT 536 Tires
KHS XCT 536 Lights
| Common Problems with KHS XCT 536 Bike |
| 1. Chain slipping or skipping gears during shifts |
| 2. Brakes squealing or not providing sufficient stopping power |
| 3. Suspension fork not functioning properly, leading to a rough ride |
| 4. Wheels going out of true, causing wobbling or vibration |
| 5. Gear shifting becoming inconsistent or not smooth |
| 6. Seat post slipping or not holding position |
| 7. Creaking or clicking noises coming from the frame or components |
User Reviews of KHS XCT 536
| Name | Review |
|---|---|
| Emily | The KHS XCT 536 bike is a great all-around mountain bike. It's lightweight, durable, and handles well on various terrains. I've taken it on some challenging trails and it has performed admirably. |
| Michael | I've been using the KHS XCT 536 for a few months now and I'm impressed with its performance. The suspension system is top-notch and provides a smooth ride even on rough trails. Definitely recommend it. |
| Sarah | This bike is a joy to ride. The frame is sturdy and the gears shift smoothly. The XCT 536 is perfect for both casual rides and more intense mountain biking adventures. I'm very happy with my purchase. |
| David | I recently upgraded to the KHS XCT 536 and I couldn't be happier. The bike is agile, responsive, and feels very reliable. It's a great choice for both beginners and experienced riders looking for a versatile mountain bike. |
Common Questions About KHS XCT 536
-
Can I upgrade the rear suspension on the KHS XCT 536?
While the rear suspension on the XCT 536 is already a RockShox Deluxe Select, you can explore other compatible options within the same travel range for potential upgrades.
-
Are the grips on the KHS XCT 536 replaceable?
Yes, the lock-on grips on the XCT 536 are replaceable, allowing you to customize them to your preferred style or material.
-
What is the maximum tire pressure recommended for the Maxxis Minion DHF tires on the XCT 536?
The recommended maximum tire pressure for the Maxxis Minion DHF tires on the XCT 536 is 35psi for optimal performance and traction.
-
Does the KHS XCT 536 come with pedals included in the package?
No, the XCT 536 does not come with pedals included, giving you the flexibility to choose pedals that match your riding preferences.
-
What is the warranty coverage for components on the KHS XCT 536?
The components of the XCT 536 are covered by a 1-year warranty, ensuring protection against defects or malfunctions within the specified period.
-
Can the KHS XCT 536 accommodate a different chainring size?
While the XCT 536 comes with a 32T chainring, you can explore options for different sizes based on your riding style and terrain preferences.
-
Is the KHS XCT 536 suitable for riders with heights outside the specified range?
The recommended height range of 5'5" to 6'3" is a general guideline. Riders outside this range can still ride the XCT 536 but may need to adjust the fit accordingly.
-
What is the type of material used for the handlebar on the KHS XCT 536?
The handlebar on the XCT 536 is made of aluminum, providing a balance of strength and lightweight performance for your riding needs.
-
Are there any additional color options available for the KHS XCT 536?
Currently, the XCT 536 is offered in Black and Red color options. Additional colors may be introduced based on market demand and availability.
-
Can I convert the KHS XCT 536 to tubeless setup?
Yes, the XCT 536 is tubeless-ready, allowing you to convert to a tubeless setup for improved traction, reduced risk of flats, and overall better performance on the trail.
