Orbea Rallon M-LTD specs
| General Information | |
|---|---|
| Model Name | Rallon M-LTD |
| Brand/Manufacturer | Orbea |
| Year of Release | 2022 |
| Country of Origin | Spain |
| Mountain Bike Type | enduro |
| Intended Use | all-mountain |
| Frame & Geometry | |
| Frame Material | carbon |
| Frame Size Options | S, M, L, XL |
| Frame Geometry | reach: 425-490mm / stack: 591-631mm / head tube angle: 65.5° / seat tube angle: 77° / chainstay length: 435mm / wheelbase: 1195-1270mm |
| Axle Standard | Boost 148mm |
| Bottom Bracket Type | BSA |
| Headset Type | IS42/IS52 |
| Internal Cable Routing | true |
| Frame Storage | downtube storage |
| Protection Features | frame armor, chainstay protector |
| Suspension System | |
| Suspension Type | full suspension |
| Front Suspension Brand and Model | Fox Float 38 Factory |
| Front Suspension Travel | 170mm |
| Rear Suspension Brand and Model | Fox Float X2 Factory |
| Rear Suspension Travel | 160mm |
| Suspension Adjustments | compression, rebound, lockout |
| Suspension Design/Kinematics | Horst Link |
| Drivetrain | |
| Drivetrain Type | 1x |
| Number of Speeds | 12-speed |
| Rear Derailleur Model | SRAM XX1 Eagle AXS |
| Shifter Brand and Model | SRAM XX1 Eagle AXS |
| Crankset Details | length: 170-175mm / chainring size: 32T |
| Cassette Range | 10-52T |
| Chain Type and Brand | SRAM XX1 Eagle |
| Q-Factor | 168mm |
| Braking System | |
| Brake Type | hydraulic disc |
| Brake Brand and Model | SRAM Code RSC |
| Rotor Size | front: 200mm / rear: 200mm |
| Brake Mount Standard | post mount |
| Brake Pads | metallic |
| Wheels & Tires | |
| Wheel Size | 29" |
| Rim Material and Width | carbon, 30mm internal |
| Hub Type and Engagement | rapid engagement |
| Tubeless Ready | true |
| Tire Brand, Model, and Width | Maxxis Minion DHF/DHR II, 2.5" |
| Tire Compound and Sidewall Casing | 3C MaxxTerra, EXO+ |
| Tire Tread Pattern and Intended Terrain | aggressive, all-mountain |
| Max Tire Pressure | 35psi |
| Insert Compatibility | CushCore-ready |
| Cockpit & Contact Points | |
| Handlebar Type | riser |
| Handlebar Material | carbon |
| Stem Length and Angle | 40-50mm, 0° |
| Grips Type | lock-on |
| Saddle Brand and Model | Fizik Gobi M5 |
| Seatpost Type | dropper |
| Dropper Post Travel | 170mm |
| Seatpost Diameter | 31.6mm |
| Headset Brand and Bearing Type | FSA, angular contact |
| Geometry & Fit | |
| Available Frame Sizes | S, M, L, XL |
| Rider Height Range | 5'6" - 6'4" |
| Stack and Reach | S: 591/425mm, M: 611/450mm, L: 631/475mm, XL: 651/490mm |
| Effective Top Tube Length | 625-665mm |
| Chainstay Length | 435mm |
| Bottom Bracket Drop and Height | 35mm/340mm |
| Head Tube and Seat Tube Lengths | 130mm/420-480mm |
| Performance & Ride Quality | |
| Weight | 29.5 lbs (claimed), 30.2 lbs (actual) |
| Ride Character | climbing, descending, stability, agility |
| Suspension Sensitivity or Progression | progressive |
| Price & Availability | |
| MSRP | $8,999 |
| Market Availability | Global |
| Color Options | Matte Grey/Black, Red/Blue |
| Warranty Coverage | frame: 5 years, components: 1 year |
Pros and Cons of Orbea Rallon M-LTD
| Pros | Cons |
|---|---|
| Excellent downhill performance | High price point |
| Efficient pedaling uphill | May be too aggressive for some riders |
| Adjustable geometry | Requires regular maintenance |
| Carbon frame for lightweight | Limited color options |
Common Issues and Problems with Orbea Rallon M-LTD
| Common Problems |
| 1. Dropper seat post not functioning properly |
| 2. Suspension settings needing frequent adjustments |
| 3. Chain dropping or shifting issues |
| 4. Brake squealing or inconsistent braking |
| 5. Wheel hub bearings wearing out prematurely |
| 6. Creaking or noisy bottom bracket |
| 7. Rear derailleur hanger alignment problems |
| 8. Handlebar grips slipping during rides |
User Reviews of Orbea Rallon M-LTD
| Name | Review |
|---|---|
| Emily | The Orbea Rallon M-LTD is an absolute beast on the trails. The suspension is smooth and responsive, making downhill sections a breeze. Climbing is also made easier with the efficient pedaling platform. Highly recommended! |
| Michael | I've been riding the Orbea Rallon M-LTD for a few months now and it has exceeded my expectations. The carbon frame is lightweight yet sturdy, and the bike handles technical terrain like a dream. Definitely a top-tier mountain bike. |
| Sarah | As an experienced rider, I can confidently say that the Orbea Rallon M-LTD is a high-performance machine. The geometry is dialed in for aggressive riding, and the components are top-notch. This bike can handle anything you throw at it. |
| James | The Orbea Rallon M-LTD is worth every penny. The Fox suspension setup is plush and tunable, allowing for a customized ride experience. Whether you're hitting jumps or navigating rocky descents, this bike delivers unmatched performance. |
Common Questions About Orbea Rallon M-LTD
-
Is the Orbea Rallon M-LTD suitable for both climbing and descending?
Yes, the Rallon M-LTD is designed to excel in both climbing and descending, offering a good balance of stability and agility.
-
What type of suspension system does the Orbea Rallon M-LTD feature?
The Rallon M-LTD comes with a full suspension system with a Fox Float 38 Factory front suspension and a Fox Float X2 Factory rear suspension.
-
Can the Orbea Rallon M-LTD accommodate different rider heights?
Yes, the Rallon M-LTD is available in various frame sizes (S, M, L, XL) to cater to a wide range of rider heights from 5'6" to 6'4".
-
What is the weight of the Orbea Rallon M-LTD?
The claimed weight of the Rallon M-LTD is 29.5 lbs, while the actual weight is around 30.2 lbs.
-
Does the Orbea Rallon M-LTD come with internal cable routing?
Yes, the Rallon M-LTD features internal cable routing, providing a clean and streamlined look.
-
What drivetrain setup does the Orbea Rallon M-LTD have?
The Rallon M-LTD features a 1x12-speed drivetrain with a SRAM XX1 Eagle AXS rear derailleur and shifter.
-
Are the wheels on the Orbea Rallon M-LTD tubeless ready?
Yes, the Rallon M-LTD comes with tubeless-ready wheels, allowing you to run lower tire pressures for better traction and control.
-
What type of brakes does the Orbea Rallon M-LTD use?
The Rallon M-LTD is equipped with hydraulic disc brakes, specifically the SRAM Code RSC model for reliable stopping power.
-
Does the Orbea Rallon M-LTD come with any frame protection features?
Yes, the Rallon M-LTD includes frame armor and a chainstay protector to guard against impacts and abrasions.
-
What is the intended use of the Orbea Rallon M-LTD?
The Rallon M-LTD is designed for all-mountain riding, making it suitable for a variety of terrain and trail types.
