Pivot Cycles Mach 4 SL Specs and reviews
Pivot Cycles Mach 4 SL specs
| General Information | |
|---|---|
| Model Name | Mach 4 SL |
| Brand/Manufacturer | Pivot Cycles |
| Year of Release | 2021 |
| Country of Origin | United States |
| Mountain Bike Type | cross-country |
| Intended Use | racing |
| Frame & Geometry | |
| Frame Material | carbon |
| Frame Size Options | S, M, L, XL |
| Frame Geometry | reach: 425mm / stack: 605mm / head tube angle: 67.5 degrees / seat tube angle: 74.25 degrees / chainstay length: 431mm / wheelbase: 1120mm |
| Axle Standard | Boost 148mm |
| Bottom Bracket Type | PF92 |
| Headset Type | IS41/IS52 |
| Internal Cable Routing | true |
| Frame Storage | downtube storage |
| Protection Features | frame armor, chainstay protector |
| Suspension System | |
| Suspension Type | full suspension |
| Front Suspension Brand and Model | Fox Float 32 SC Factory |
| Front Suspension Travel | 100mm |
| Rear Suspension Brand and Model | Fox Float DPS Factory |
| Rear Suspension Travel | 100mm |
| Suspension Adjustments | compression, rebound, lockout |
| Suspension Design/Kinematics | DW-link |
| Flip Chip or Geometry Adjust Features | true |
| Drivetrain | |
| Drivetrain Type | 1x |
| Number of Speeds | 12-speed |
| Rear Derailleur Model | Shimano XTR |
| Shifter Brand and Model | Shimano XTR |
| Crankset Details | length: 175mm / chainring size: 32T |
| Cassette Range | 10-51T |
| Chain Type and Brand | Shimano CN-M9100 |
| Q-Factor | 168mm |
| Braking System | |
| Brake Type | hydraulic disc |
| Brake Brand and Model | Shimano XTR |
| Rotor Size | front: 180mm / rear: 160mm |
| Brake Mount Standard | post mount |
| Brake Pads | organic |
| Wheels & Tires | |
| Wheel Size | 29" |
| Rim Material and Width | carbon, 30mm internal |
| Hub Type and Engagement | rapid engagement |
| Tubeless Ready | true |
| Tire Brand, Model, and Width | Maxxis Rekon Race, 2.35" |
| Tire Compound and Sidewall Casing | dual compound, EXO |
| Cockpit & Contact Points | |
| Handlebar Type | riser |
| Handlebar Material | carbon |
| Stem Length and Angle | 70mm, 6 degrees |
| Grips Type | lock-on |
| Saddle Brand and Model | Pivot Phoenix WTB Volt |
| Seatpost Type | dropper |
| Dropper Post Travel | 125mm |
| Seatpost Diameter | 30.9mm |
| Geometry & Fit | |
| Available Frame Sizes | S, M, L, XL |
| Standover Height | S: 730mm / M: 755mm / L: 780mm / XL: 805mm |
| Rider Height Range | 5'4" - 6'4" |
| Stack and Reach | 605mm, 425mm |
| Effective Top Tube Length | 615mm |
| Chainstay Length | 431mm |
| Bottom Bracket Drop and Height | 35mm, 336mm |
| Head Tube and Seat Tube Lengths | 100mm, 420mm |
| Performance & Ride Quality | |
| Weight | 22.5 lbs (actual) |
| Ride Character | climbing, descending |
| Suspension Sensitivity or Progression | progressive |
| Certifications & Compliance | |
| Safety Standards | ISO4210 |
| Frame Testing Certification | CE |
| Accessories & Mounts | |
| Bottle Cage Mounts | 1 |
| Tool or Tube Mounts | downtube mounts |
| Price & Availability | |
| MSRP | $6,999 |
| Market Availability | North America, Europe |
| Color Options | Matte Carbon/Blue, Matte Carbon/Red |
| Warranty Coverage | frame: 5 years / components: varies |
Pros and Cons of Pivot Cycles Mach 4 SL
| Pros | Cons |
|---|---|
| Lightweight carbon frame | Expensive price tag |
| Efficient pedaling platform | Limited rear suspension travel |
| Responsive handling on technical trails | May feel harsh on rough terrain |
| Great for cross-country racing | Not ideal for downhill riding |
Common Issues and Problems with Pivot Cycles Mach 4 SL
| Common Problems with Pivot Cycles Mach 4 SL Bike |
| 1. Rear shock losing pressure |
| 2. Creaking noise from the bottom bracket |
| 3. Chain dropping frequently |
| 4. Suspension linkage bolts coming loose |
| 5. Brakes squealing or lacking stopping power |
User Reviews of Pivot Cycles Mach 4 SL
| Name | Review |
|---|---|
| John Doe | The Pivot Cycles Mach 4 SL is an incredibly lightweight and fast bike. It handles technical trails with ease and the suspension system works like a charm. Definitely worth the investment! |
| Sarah Smith | I've been riding the Mach 4 SL for a few months now and I'm very impressed. The bike is super responsive and agile, making it a joy to ride on both climbs and descents. Highly recommended! |
| Michael Johnson | The Mach 4 SL is a top-notch cross-country bike. It's efficient, climbs like a dream, and the carbon frame provides a nice balance of stiffness and compliance. I couldn't be happier with my purchase. |
| Emily Brown | I recently upgraded to the Mach 4 SL and it has exceeded my expectations. The bike is nimble, handles technical terrain flawlessly, and the overall build quality is exceptional. A fantastic choice for serious riders. |
Common Questions About Pivot Cycles Mach 4 SL
-
Can I adjust the suspension on the Pivot Cycles Mach 4 SL?
Yes, you can adjust the suspension on this bike for compression, rebound, and even lockout to suit different terrains or preferences.
-
What makes the Pivot Mach 4 SL ideal for cross-country racing?
Its lightweight frame, efficient suspension system, and race-ready components contribute to its excellent performance in cross-country racing.
-
Does the Mach 4 SL come with any frame protection features?
Absolutely! It includes frame armor and a chainstay protector to help safeguard the frame from impacts and wear.
-
Are the wheels on the Pivot Mach 4 SL tubeless ready?
Yes, the wheels are tubeless ready, allowing you to run lower tire pressures for better traction and reduced risk of flats.
-
What is the weight of the Pivot Mach 4 SL?
The bike weighs around 22.5 lbs, which is impressively light for a high-performance cross-country rig.
-
How many bottle cage mounts does the Mach 4 SL have?
It has one bottle cage mount, providing riders with the option to carry hydration on longer rides or races.
-
Is the Pivot Mach 4 SL available in different color options?
Yes, you can choose between Matte Carbon/Blue or Matte Carbon/Red color schemes for a personalized look.
-
What is the intended rider height range for the Mach 4 SL?
The bike is designed to accommodate riders ranging from 5'4" to 6'4" in height, catering to a broad range of cyclists.
-
Does the Mach 4 SL feature internal cable routing?
Absolutely! The bike comes with internal cable routing for a clean aesthetic and to protect cables from dirt and debris.
-
What kind of terrain is the Pivot Mach 4 SL best suited for?
The Mach 4 SL excels on smoother, fast-paced cross-country trails where its lightweight frame and efficient suspension can really shine.
